Coolant
External
Hand
Right
Unit: inch
DC
10
DCX
10.506
LF
2.5
APMX
0.197
OAL
2.5
DCONMS
2.5
DCSFMS
8.661
NOF
14
ZEFF
14
ZEFP
14
KAPR
45
RPMX
7500
GAMF
-10
GAMP
-6
WT
29.200
