- Dimensions
- Features
- Drawings
- Technical Information

Coolant
Internal
Hand
Right
Unit: inch
DC
5.835
DCX
6.299
LF
2.48
APMX
0.079
OAL
2.48
DCONMS
2
DCSFMS
3.937
NOF
6
ZEFF
6
ZEFP
6
KAPR
22
RMPX
0.5
GAMF
-5
GAMP
8
WT
11.486
