EDP
556092
ANSI
MMS1360X5DB DP7020
ISO
MMS1360X5DB DP7020
Stock
2
Price
Regular price
$485.57 USD
Regular price
Sale price
$485.57 USD
Unit price
/
per
EDP
556092
ANSI
MMS1360X5DB DP7020
ISO
MMS1360X5DB DP7020
Change the number in sums of 1s.
- Dimensions
- Features
- Drawings
- Technical Information
Coolant
Internal
Hand
Right
Unit: mm
DC
13.6
ULDR
5
LU
70.5
LCF
100.5
OAL
156.5
DCONMS
14
PL
2.5
SIG
140
FHA
30
DC Max
0
DC Min
-0.027
TCDCON
h6
ZEFF
2
Unit: mm
DC
13.6
ULDR
5
LU
70.5
LCF
100.5
OAL
156.5
DCONMS
14
PL
2.5
SIG
140
FHA
30
DC Max
0
DC Min
-0.027
TCDCON
h6
ZEFF
2
New grade DP7020 and a unique margin, developed specifically for stainless steel, complement high flow coolant holes.
Long drill life and high efficiency drilling of holes in stainless steel.
