EDP

621641

ANSI

VQMHZV/1.4

ISO

VQMHZVD0140

P (Steel) M (Stainless) N (Non-Ferrous) S (Heat-Resistant)

21

Regular price $37.18 USD
Regular price Sale price $37.18 USD
Sale

EDP

621641

ANSI

VQMHZV/1.4

ISO

VQMHZVD0140

P (Steel) M (Stainless) N (Non-Ferrous) S (Heat-Resistant)
View full details
  • Dimensions
  • Features
  • Drawings
  • Technical Information
VQMHZVD0140
Coolant
External
Hand
Right

Unit: mm

DC
1.4
APMX
2.8
LU
2.8
LH
3.2
OAL
45
DCONMS
4
BHTA2
15
FHA
45
ZEFP
3
ZEFF
3
VQMHZVD0140

Unit: mm

DC
1.4
APMX
2.8
LU
2.8
LH
3.2
OAL
45
DCONMS
4
BHTA2
15
FHA
45
ZEFP
3
ZEFF
3
