diaedge
MVS1786X03S180 DP1020
Skip to product information

The actual product may differ from the displayed image.

Skip to product information

The actual product may differ from the displayed image.

1 of 2

EDP

694057

ANSI

MVS1786X03S180 DP1020

ISO

MVS1786X03S180 DP1020

P (Steel) M (Stainless) K (Cast Iron) N (Non-Ferrous) S (Heat-Resistant)

11

Regular price $444.71 USD
Regular price Sale price $444.71 USD
Sale

EDP

694057

ANSI

MVS1786X03S180 DP1020

ISO

MVS1786X03S180 DP1020

P (Steel) M (Stainless) K (Cast Iron) N (Non-Ferrous) S (Heat-Resistant)
View full details
  • Dimensions
  • Features
  • Drawings
  • Technical Information
MVS1786X03S180 DP1020
Coolant
Internal
Hand
Right

Unit: inch

DC
0.7031
ULDR
3
LU
2.239
LCF
3.673
OAL
6.23
DCONMS
0.709
PL
0.128
SIG
140
FHA
30
DC Max
0
DC Min
-0.0011
TCDCON
h6
ZEFF
2
MVS1786X03S180 DP1020

Unit: inch

DC
0.7031
ULDR
3
LU
2.239
LCF
3.673
OAL
6.23
DCONMS
0.709
PL
0.128
SIG
140
FHA
30
DC Max
0
DC Min
-0.0011
TCDCON
h6
ZEFF
2
